Tip HD 100
Telemetre cu laser
Instructiuni
Aparat de măsurare a distanţei precizie de până la 100 m precizie 1.5 mm, permite măsurarea în condiţii de siguranţă pentru a dificil de a ajunge sau locuri periculoase. Calculează zone, volume, dimensiunile camerei, şi diverse tipuri de funcţii lui Pitagora. Built-in senzor de înclinare determină pur şi simplu, rapid şi unghiurile verticale de până la ± 45 °. Timer stabilitate funcţia creşte atunci când se iau măsurători. Afişajul este iluminat automat pentru măsurători uşoare în condiţii de iluminare slaba, întuneric. bucată sfârşitul multifuncţional permite măsurarea din colţuri, sloturi sau de la margini. Instrumentul detectează piesa capăt în mod automat, ceea ce contribuie la evitarea erorilor de măsurare costisitoare. Rezistenta la apa IP54 pentru utilizare în toate condiţiile. Sistemul conţine o husa, curea de mână, plăcuţe ţintă, şi ghidul utilizatorului.
Nivele cu laser liniar
Spectra Precision 5.2XL - Puncte si linie laser		LG20 - generator linie in cruce
Prezentare		Prezentare
Nivela cu laser cu 5 puncte laser si 2 linii incrucisate. Cu suport de prindere universal. Receptia liniei posibila cu receptorul optional tip HR 250		Nivela cu laser in cruce, autonivelanta. Carcasa rezistenta la soc. Posibilitate de utilizare cu receptor electronic tip HR 250
LP20 - 2 puncte laser		LP40 - 4 puncte laser

LP 20 Nivela cu laser cu doua fascicule, unul in jos, altul in sus. Functia "fir cu plumb" - Distante maxime recomandate: - 30 m punct in sus Autonivelant. Carcasa rezistenta chiar in cazul caderii pe ciment de la 1m inaltime LP40 Nivela cu laser cu 4 fascicule. Pe cele 3 ate: 1. Fir in jos 2. Punct in sus 3. Punct in fata 4. Punct dreapta Carcasa rezistenta chiar in cazul caderii pe ciment de la 1m inaltime		LP 40 - 4 puncte laser disponibil si cu accesoriu universal de fixare pe perete, tavan, etc - LP 40-1 Prezentare LP20/LP40
Receptoare electronice diverse tipuri de nivele laser

Receptor-HR150	Receptor-HR320	Receptor-HR350
Receptor-HR450	Receptor-HR750	Receptor-CR600
Nivele laser rotative
Spectra Precision® Laser LL100		Spectra Precision Laser LL300
Prezentare Instructiuni Nivela laser rotativa LL 100 cu receptor inclus tip HR 320 LL100 Laser Specifications Laser Source . . . . . . . . . . . . . 650 nm visible, Class 2 Laser Accuracy. . . ±1/8 in at 100 ft (±3 mm at 30 m) Operating Range (Diameter) w/HR320 receiver. . . . . 1,000 ft (300 m) Self-Leveling Range . . . . ±5 degrees Compensation Method. . . . . . Electronic self-leveling Drop Height on Concrete performance. . . . . 3 ft (1 m) Single Axis Manual Slope Mode . . . . . . . . . . . . . Yes Out of Level (HI) Warning . . . . . . . . . . . . . . . . . . Yes Power Source. . . . . . . 2 “D” alkaline Battery Life. . . . . . . . . . . . . . . . . . . . . . . 80 hours Rotation Speed. . . . . . . . . . . . . 600 RPM Tripod Mount (Horizontal and Vertical). . . . . 5/8” x 11 Operating Temperature. . . . . . 23 to 113°F (-5 to 45°C) Storage Temperature . . . . . -4 to 158°F (-20 to +70°C) Water Resistant . . . . . . . . Yes, IP54 sealing Size. . . . . . . 8.5 x 6.7 x 6.0 in (22 x 17 x 15 cm) Weight. . . . . . 3.3 lbs (1.5 kg)		Prezentare Instructiuni Nivela laser rotativa 400 m diametru LL300 Laser Specifications Laser Source . . . 635 – 670 nm visible, Class 3A/3R Laser Accuracy. . . . 3/32 in per 100 ft (2.2 mm per 30 m) 15 arc seconds Operating Receiver Range (Diameter). . . . . 1,300 ft (400 m) w/HL450 or CR600 Receiver Self-Leveling Range . . . . . . . . . . . . . . . . . ±5º Compensation Method. . . . . Electronic Self Leveling Power Source. . . . . 4 “D” Rechargeable or Alkaline Batteries Battery Life. . . . . . Rechargeable: 45 hours, Alkaline: 90 hours Battery Status LED. . . . . . . . Flashing Red LED Battery Recharging Time. . . . . . . . Less than 10 hours Rotation Speed. . . . . . . . . . . . . . 600 rpm Out of Level (HI)-Warning. . . . . . . . Rotor stops, red out-of-level LED blinks Out of Level Warning at Receiver. . . . Programmable at dealer (with CR600 receivers only) Machine Control Compatible. . . . . . Yes Protective Rotor Cage (removable) . . . . . . . . . . . . . . Yes Drop Height on Concrete. . . . . . . . . . . . . . . . 3 ft (1 m) Single Axis Manual Slope Mode. . . Yes (w/self-leveling mode on the second axis), with optional RC601 remote control External Remote Control (Operating Range) . . . . . . . . . 160 ft . (up to 50 m ) Tripod Mount (Horizontal and Vertical). . . . . . . . . 5/8"–11 Operating Temperature. . . . . –4 ºF to 122 ºF (–20 ºC to +50 ºC) Storage Temperature . . . . . . –4 ºF to 158 ºF (–20 ºC to +70 ºC) Waterproof. . . . . . . . . . . . . . . . Yes, IP54 Size. . . . . . 9.6L × 6.5W × 7.3H in (24.5L × 16.5W × 18.5H cm) Weight. . . . . . . . . . . 6 lbs (2.7 kg
Spectra Precision Laser LL400		Spectra Precision Laser LL500
Prezentare Instructiuni		Prezentare Instructiuni
Nivela laser rotativa - 800 m. Laser Source . . . . . . 650 nm visible, Class 2 Laser Accuracy. . . . ±1.5 mm at 30 m (±1/16 in at 100 ft) Operating Receiver Range (Diameter) w/HL700 receiver. . . . . . . . . . . . . 800 m (2,600 ft) Compensation Method. . . . . . . . . . . . Electronic self-leveling Temperature Calibrated . . . . . Yes Self-Leveling Range . . . . ±5 degrees Machine Control Compatible . . . . . . . . . . . . . . . . . . . Yes Ruggedized lighthouse. . . . . . . . . . . . . . . . . . . . . . . . . . . . . Yes Drop Height on Concrete performance. . . . . 1 m (3 ft) Remote Control Range (Optional RC601). . . . . . . . . . 200 m (650 ft) –X side, up to 50 m (160 ft) all other sides Single Axis Slope Mode . . . . . . . . Yes (both axes) Out of Level (HI) Warning . . . . . . . . . Yes Power Source. . . . . 4 “D” Alkaline Standard, NiMH Optional Battery Life. . . . . . . . . . . . . 90 hours Alkaline, 55 hours NiMH Battery Status LED . . . . . . . . . . . . . Flashing red LED Battery recharging time . . . . . . . . Less than 10 hours Rotation Speed. . . . . 600 RPM Tripod Mount (Horizontal and Vertical). . . . . . . . . . . 5/8” x 11 Out-of-Level warning . . . . . . Rotor stops, laser shuts off, red HI-alert LED flashes Operating Temperature. . -20 to +50°C (-4 to +122°F) Storage Temperature . . . . -20 to +70°C (-4 to 158°F) Dust and Waterproof . . . . .. . . . . . . . . . . . . Yes, IP66 Size. . .. . 21L x 18W x 20H cm (8.3L x 7.1W x 7.9T in) Weight. . . . . . . . . 3.1 kg (6.8 lbs) Warranty. . . . . . . . . . . . . . 2 years		Nivele laser rotativ gama LL500 Spectra LL500 Laser Specifications Self-Leveling Range . . . . . . . . . . . . . . . . . . . ± 11 arc minutes Compensation Type. . . . . . . . . . . . . . Wire Hung, Air Damped Accuracy. . . . . . . . . . . . . . . . 1.5 mm at 30 m (1/16 in at 100 ft) ±10 arc seconds Temperature Compensation. . . . . . . . . . . . . . . . . . Yes Laser Type. . . . . . . . . . . . 670 nm visible, Class II Machine Control Compatible. . . . . . . . . . . . . . . . . . . . Yes Battery Life 20°C (68°F). . . . . . . . 4 D-Cell Alkaline - 175 hrs NiMH - 100 hrs, NiCad - 75 hrs Operating Diameter. . . . . . . . . . . . . . . 500 m (1,600 ft) Operating Temperature. . . . . . . -20°C to 50°C (-4°F to 122°F) Weight. . . . . . . . . . . . . . . . . . . . . . . . 3.6 kg (8 lbs) Tripod Mount. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5/8 in x 11 Warranty. . . . . . . . . . . . . . . . 2 Years Use-and-Abus
Spectra Precision Laser HV101		Spectra Precision Laser HV301
Prezentare Instructiuni		Prezentare Instructiuni
Nivela laser rotativa, orizontal, vertical HV 101 HV101 Laser Specifications Laser Source . . . . . . . . <5 mW @ 635 nm, Class 3A Laser Accuracy . . . . . . ±1/8 in at 100 ft (±3 mm at 30 m) (±20 arc seconds) Operating Range . . .. . 100 ft (30 m) minimum visual 1,000 ft (300 m) diameter with receiver Self-leveling Range . . . . . . . . . . . . . . . . . ±5 degrees Compensation Method . . . . . . Electronic self-leveling Power source . . . . . . . . . . 2 x “D” Alkaline Batteries Battery life . . . . . . . . . . . . . . . 50 hours Alkaline 45/25 hours user provided Ni-MH/Ni-CD Battery Status LED . . .. . . . . . . . . . Flashing red LED Rotation speed . . . . . . . . . . . . . . . . Four preset speeds 0, 50, 200, 600 RPM Scan angles . . . . . . . . . . . . . . . . . . . .Five preset angles 3°, 8°, 45°, 90°, 180° Out-of-level warning . . . .Rotor stops, laser shuts off, red out-of-level LED flashes Operating temperature . . . . . . . . . . . . . . . . . . 23 °F to 113 °F (-5 °C to 45 °C) Storage temperature . . . . . . . . . . . . . . . . . . . -4 °F to 158 °F (-20 °C to 70 °C) Warranty . . . . . . . . . . . . . . . . . . . . . . . . 3 Year Limited with Instant Exchange Water resistant . . . . . . . . . . . . Yes, and IP54 sealing Size . . . . . . . . . . . . . . . . . . .8.5L × 6.7W × 6.0H in (21.6L × 17.1W × 15.2H cm) Weight . . . . . . . . . . . . . . . . . . . . . . 3.3 lbs (1.5 kg)		Nivela laser HV 301 HV301 Laser Features • High durability with IP54 sealing • Automatic self-leveling for level and plumb • Temperature compensation for accurate outdoor use regardless of season • Highly visible beam • Flexible power options and battery recharge port • Intuitive, one-touch operator controls • Built-in vertical stand and 5/8” × 11” H/V mounting • Manual slope control to match known references • Wall mount feature allows vertical setups with no extra accessories HV301 Laser Specifications Laser source. . . . . . . . . <5 mW nominal Laser accuracy . . . ±3/32 in at 100 ft (±2.2 mm at 30 m) (±15 arc seconds) Temperature compensation. . . . . . . . . Yes (2 arc seconds / °C) Self-leveling range . . . . . . . . . . . ±5 degrees Compensation method . . . . . . Electronic self-leveling Power source. . . . . . . . . Rechargeable or alkaline batteries Battery life. . . 40 hours rechargeable, 90 hours alkaline Battery Status LED. . . . . . . Flashing red LED Battery recharging time. . . . . . . . . . . . . . Less than 10 hours Rotation speed. . . . . . . . . . . . . . . Four preset speeds from zero to 600 rpm Out-of-level warning. . . . . . . . . Rotor stops, laser shuts off, red out-of-level LED flashes Operating temperature. . . . . . . -20 °C to 50 °C (-4 °F to 120 °F) Storage temperature. . . -20 °C to 70 °C (-4 °F to 158 °F) Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 years Water resistant. . . . . . . . . . Yes, and IP54 sealing Size. . . . . 24.5L × 16.5W × 18.5H cm (9.6L × 6.5W × 7.3H in) Weight. . . . . . 2.7 kg (6 lbs)
Laser HV301G Horizontal Vertical Laser - verde		Spectra Precision Laser HV401 Interior
Prezentare Instructiuni Nivela laser rotativ orizontal/vertical, de culoare verde. HV301G Laser Specifications Laser type. . . . . . . . . . . . . . . .532 nm Green Beam Laser class. . . . . Class 3R / IIIa, <5mW Laser accuracy . . . . . ±3/32 in at 100 ft (±2.2 mm at 30 m, ±15 arc seconds) Interior range. . . . . . . . . . . up to 250 ft (75 m) Temperature compensation. . . . . . . . . . . Yes (2 arc seconds / °C) Self-leveling range . . . . . . . . . . . . . . . . ±5 degrees Compensation method . . . . . . . Electronic self-leveling Power source. . . . . . 4 ‘D’ size NiMH batteries standard (Alkaline optional) Battery life. . . . . . . . 18 hours rechargeable, 45 hours alkaline Battery status LED. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Flashing red LED Battery recharging time. . . . . . Less than 10 hours Rotation speed. . . . . . . . . . . . 0/10/80/200/600 rpm Scanning angles . . . . . . Four preset angles 8°/45°/90°/180° Operating temperature. . . . . . . . 32 °F to 104 °F (0 °C to 40 °C) Storage temperature. . . . . . . . . -4 °F to 158 °F (-20 °C to 70 °C) Water resistant. . . . . . . . . . . Yes, and IP54 sealing Size. . . . . . . . . 9.6L × 6.5W × 7.3H in 2 (4.5L × 16.5W × 18.5H cm) Weight. . . . . . . . 6 lbs (2.7 kg) Warranty . . . . . . . . . . . . . . . . . . . . . . . 2 years		Prezentare Instructiuni Nivela laser rotativa tip HV401 HV401 Laser Specifications Laser source 5 mW, class 3A/3R, 635 nm Laser accuracy ± 1.5 mm at 30 m (± 1/16 in at 100 ft) (±10 arc seconds) Remote control range 200 m (650 ft) -X side, up to 50 m (160 ft) for outside applications Self-leveling range ±5 degrees Drop height on concrete 1 m (3 ft) Compensation method Electronic self-leveling Receiver operating diameter 800 m (2,600 ft) Power source NiMH standard, alkaline backup Battery life 55 hours NiMH, 90 hours alkaline Rotor plumb vial Fast beam positioning in the down plumb position to 1.5 mm at 1 m (1/16” at 3 ft) Battery status LED Flashing red LED Battery recharging time Less than 10 hours Rotation speed Four preset speeds from 10 to 600 rpm Temperature calibrated Yes Out-of-level warning Rotor stops, laser shuts off, red HI-alert LED flashes Operating temperature............... -20 °C to 50 °C (-4 °F to 122 °F) Storage temperature ...................-20 °C to 70 °C (-4 °F to 158 °F) Waterproof and dustproof Yes, IP66 Size ......................... 21L × 18W × 20H cm (8.3L × 7.1W × 7.9T in) Weight 3.1 kg (6.8 lbs) Warranty 2 years
Spectra Precision Laser GL412 - inclinari pe 2 axe		Spectra Precision Laser GL422 - inclinari pe 2 axe
Prezentare Instructiuni		Prezentare Instructiuni
Nivela laser rotativa cu afisaj grade , inclinare pe o axa. GL412 and GL422 Features • Fast, easy horizontal level, grade and vertical plumb setup with no manual leveling • Quick payback due to easy setups with the 2-way radio remote control, and single and dual grade application capability • No rework due to automatic temperature and grade compensation • Very long operating range – 800 m (2,600 ft) diameter (GL422 only) for increased machine control capability and fewer setups over the job site • Very rugged with low service costs, takes a drop of up to 1 m (3 ft) onto concrete • Mask mode eliminates interference with other crews on the job site • Pointing mode allows “Over the Top” pipe laying for house connections • Reduced material cost with virtually no downtime Specifications Laser type / class. . . . . . <5 mW 635 nm, Class 3A/3R (GL422) 3 mW 650 nm, Class 2 (GL412) Drop height on concrete . . . . . . . . . . . . . . . . . . . . 1 m (3 ft) Operating diameter (w/ HL700). . . . . 800 m, 2600 ft (GL422) 600 m, 2000 ft (GL412 Compensation method . . . . . . . H/V Electronic Self Leveling Temperature compensation. . . . . . . . . . . . . . . . Yes, every 5 °C Level / vertical accuracy. . . . . . . . . . . . . . . . . 10 arc seconds 1.5 mm @ 30 m (1/16" @ 100 ft) Grade range. . . . . . . . . . –10 to +15% Dual Axes (GL422)–10 to +15% Single Axis (GL412) Grade accuracy. . . . . . . . 0.015% 3 mm@30 m (1/8" @ 100 ft) Grade resolution . . . . . . . . . . . . 0.001% up to 9.999%, 0.01 % at higher grades Grade compensation. . . . . . . . . . . . . . . . . . . . . . Yes Remote control type . . . . . . . Full 2-way communication, operation and security lock with transmitter Remote control range (w/ RC402). . . . . . 100 m (330 ft) radius Rotation speed. . . . . . . . . 0 (GL422), 300, 600 RPM selectable Transmitter battery life (4 x D NiMHs). . . . . 55 hours RC402 battery Life (2 x AA Alkaline). . . . . 130 hrs continuous 1 year under normal use Mask mode. . . . . . . User selectable to any window 3 windows maximum Standby mode. . . . . . . . . . . . . . Yes Display backlight. . . . . Yes, auto shutoff after 8 seconds Mounting threads . . . . . . 5/8" x 11 Horizontal and Vertical Operating temperature. . . . . . . –20° to +50°C (–4° to 122°F) Dimensions. . . . . 21L x 18W x 20H cm (8.3L x 7.1W x 7.9H in) Weight. . . . . . . . . . . . . . . . . . . . . . . . . 3.1 kg (6.8 lb) Warranty. . . . . . . . . . . . . . . . . . . . . . . . . 2 Years
Spectra Precision Laser GL512 - inclinari pe 1 axe		Spectra Precision Laser GL522 - inclinari pe 2 axe
Prezentare Instructiuni		Prezentare Instructiuni
GL512 and GL522 Features • Automatic electronic self-leveling provides fast, easy level, grade, and vertical alignment setups • Single or dual grade application capability • Full function 2-way radio remote control has the same functions and display as the laser keypad • Very long operating range – 800 m (2,600 ft) diameter (GL522) for increased machine control capability and fewer setups over the jobsite • Radio communication between the HL750 and the laser provide automatic Grade Matching and PlaneLok • Electronic Leveling Vibration Filter dampens vibrations typically experienced in high winds or on high vibration job sites • Automatic temperature and grade compensation keep the units accurate throughout the day or night • Very rugged with low service costs; takes a drop of up to 1 m (3 ft) onto concrete • Mask mode eliminates interference with other crews on the jobsite • Pointing mode allows “Over the Top” pipe laying for house connections (GL522) • High capacity Nickel-Metal Hydride battery pack reduces operating costs Specifications Laser type/class . . . <5 mW 635 nm, Class 3A/3R (GL522) 3 mW 650 nm, Class 2 (GL512) Drop height on concrete . . . . . . 1 m (3 ft) Operating diameter (w/ HL750). 800 m, 2600 ft (GL522) 600 m, 2000 ft (GL512) Compensation method. . H/V Electronic Self Leveling Temperature compensation. . . . . . Yes, every 5 °C Level / vertical accuracy. . . . . 10 arc seconds 1.5 mm @ 30 m (1/16" @ 100 ft) Grade range. . . . . . . –10 to +15% Dual Axes (GL522)–10 to +15% Single Axis (GL512) Grade accuracy.. 0.015% 3 mm@30 m (1/8" @ 100 ft) Grade resolution . . . . . . . . 0.001% up to 9.999%, 0.01 % at higher grades Grade compensation. . . . . . . . . . . . . . . . . . . . . Yes Transmitter battery life (4 x D NiMHs). . . . 55 hours Mask mode. . . User selectable to any window, 3 max. Remote control type . . . . Full 2-way communication, operation and security lock with transmitter Remote control range. . . . . . . . . 100 m (330 ft) radius Rotation speed. . . 0 (GL522), 300, 600 RPM selectable RC402 battery Life (2 x AA Alkaline).. 130 hrs continuous 1 year under normal use Standby mode. . . . . . . Yes Display backlight. . . . Yes, auto shutoff after 8 seconds Mounting threads. . . 5/8” x 11 Horizontal and Vertical Operating temperature . . . –20° to +50°C (–4° to 122°F) Dust and waterproof. . . . . . . Yes - IP66 Dimensions.. 21L x 18W x 20H cm (8.3L x 7.1W x 7.9H in) Weight. . . . . . . . . . . . . . . 3.1 kg (6.8 lb) Warranty. . . . . . . . . . . . . . . . . . . . . . . . 2 Years
Spectra Precision Laser GL710, 720, 742 - inclinari, raza mare pentru telecomanda
Prezentare Instructiuni Instructiuni pe scurt Brosura
Nivela cu laser rotativ cu afisaj inclinari de pana la 25 % pe o axa GL710 GL710 single Grade An easy-to-learn, easy-to-use one-person grade laser, economical and accurate up to a 900 m (3,000 ft) diameter. Ideal for general construction, site preparation, trenching and pipe laying applications. Range (Diameter) 900 m (3,000 ft) Radio Remote No Auto Axis Alignment No Grade Match Mode No PlaneLok No Axis Grade Range X NA Axis Grade Y -0.5 to +25%		Nivela electronica cu afisaj inclinare pe 2 axe GL720: axa X - 10 % si axa Y de la -0.5 la +25% This economical choice has +/-10% in the X-axis grade range and -0.5 to +25% Y-axis grade range with high accuracy up to 900 m (3,000 ft) diameter. Ideal for general construction and machine control grade applications. Grade ranGe accuracY Axis Grade Range X -10 to +10% (GL710, GL720, GL722) -5 to +5% (GL742) Axis Grade Range Y -0.500 to +110% (GL742) -0.500 to +25% (GL720, GL722) Self-Leveling GL710 self levels to 10% GL720, GL722, GL742 self level to 25% Grade Resolution 0.001% Servo Deadband Accuracy 4.6 arc seconds (GL710, GL720, GL722, GL742) laser classiFication CDRH II (IECI) ranGe/radius Laser – 450 m (1500 ft) with Spectra Precision Lasers machine-mounted receivers MountinG threads 5/8” x 11” on all models 3 1/2” X 8” Mounting Adapter optional WaterProoF & housinG Waterproof Aluminum Housing diMensions Weight 8.5 kg (18.8 lbs) Size Height 29.8 cm (11.75 in) Width 25.4 cm (10.0 in) Depth 19.7 cm (7.75 in) Range (Diameter) 900 m (3,000 ft) Radio Remote No Auto Axis Alignment No Grade Match Mode No PlaneLok No Axis Grade Range X -10 to +10% Axis Grade Y -0.5 to +25%	Nivela electronica cu afisaj inclinare pe 2 axe GL722: With Long-range Radio Remote and with the same range and base capabilities as the GL720, the GL722 includes the benefits of the full Radio Remote functions… plus Automatic Axis Alignment capability. Ideal for general construction, site preparation and road construction. Grade ranGe accuracY Axis Grade Range X -10 to +10% (GL710, GL720, GL722) -5 to +5% (GL742) Axis Grade Range Y -0.500 to +110% (GL742) -0.500 to +25% (GL720, GL722) Self-Leveling GL710 self levels to 10% GL720, GL722, GL742 self level to 25% Grade Resolution 0.001% Servo Deadband Accuracy 4.6 arc seconds (GL710, GL720, GL722, GL742) laser classiFication CDRH II (IECI) ranGe/radius Laser – 450 m (1500 ft) with Spectra Precision Lasers machine-mounted receivers MountinG threads 5/8” x 11” on all models 3 1/2” X 8” Mounting Adapter optional WaterProoF & housinG Waterproof Aluminum Housing diMensions Weight 8.5 kg (18.8 lbs) Size Height 29.8 cm (11.75 in) Width 25.4 cm (10.0 in) Depth 19.7 cm (7.75 in)
Nivele optice
AL24A/M, AL28A/M, AL32A Autolevels
Prezentare
Marirea lentilei 24X, 28X, 32 X - Precizia +/1,5 mm, 2mm, - Cea mai scurta distanta masurata : 0,6 m - Compensator aer, magnetic
Spectra Precision® DET-2 Construction Theodolite
Teodolit electronic cu 2 displayuri, pentru masurare de unghiuri pe doua axe orizontal si vertical. 2" Accuracy of Angle Measurement Vertical Compensation ± 3' 30 x Magnification of Telescope 3 x Optical Plummet Prezentare Instructiuni
Statie Totala - Trimble TS 215
Prezentare
Performance Specifications Angle Measurement Accuracy (Standard deviation based on DIN18723) . . 5" (1.5 mgon) Angle reading increments . 1"/5"/10" (0.2 mgon/ 1 mgon/ 2 mgon) Automatic level compensator . . . Single-axis compensator Distance Measurement Prism Mode Standard measurement. . ±3 mm + 2 ppm (0.01 ft + 2 ppm) Tracking . . ±10 mm + 2 ppm (0.032 ft + 2 ppm) Measuring Time Prism Mode Standard measurement. . . 1.6 s Tracking . . . 1.0 s Range (at Standard Clear) Measurement to Prism 1 prism (50 mm dia.) . . . 2,300 m (7,500 ft) 3 prisms. . . . . . . . . . . 3,000 m (9,800 ft) Range with Nikon specified prisms Good conditions (No haze, visibility over 40 km [25 miles]) With reflector sheet (5 x 5 cm). . . . . 5 m to 100 m (16.4 ft to 328 ft) With mini prism 2.5 cm (1 in). . . . . . 1,200 m (3,930 ft) With single prism 6.25 cm (2.5 in) . . . . . 2,3000 m (7,540 ft) With triple prism. . . 3,000 m (9,840 ft) General SPECIFICATIONS Optical plummet . . . . . . Optical 3x Telescope Magnification. . . 33x Aperture. . . . . . 45 mm (1.77 in) Illuminated crosshair. . . . . . No Display screen. . . . . . . . Single side - graphic LCD (128 x 64 pixel) Operating temperature. . . . . . –20 ºC to + 50 ºC (–4 ºF to 122 ºF) Battery Type. . . . 4x AA Ni-MH Batteries, rechargeable Charge time. . . . . . . . . . . . . . . . . . . . Approximately 3.7 hours Operating time. . . . . Approximately 12–15 hours Class II laser product label. . . . . . No DATA TRANSFER AND RECORDING Data input/output. . . . . . RS232 LM80 interface. . . . . . . Optional
